Baby Lock Alliance


The Alliance single-needle, free-arm machine lets you embroider easily in tight quarters and even on three-dimensional projects. Its narrow embroidery arm and specially designed small hoops and frames take your embroidery places not possible with other machines—inside pockets, sleeves, even embroiderable stuffed animals!

1 in stock (can be backordered)

Product price
Additional options total:
Order total:


TruView™ LCD Color Touch Screen™

This high-definition TruView LCD color touch screen brings your embroidery designs to life. It displays more than 260,000 colors, providing a bold and vivid image to aid the embroiderer in editing and perfecting each design.

Single-Needle, Free-Arm Embroidery

With its single needle and free arm, the Alliance is built to embroider items and three-dimensional spaces that are difficult for typical embroidery machines, such as inside pockets, embroiderable stuffed animals, or even shoes.

Needle Beam for Embroidery

The Needle Beam highlights your needle position so you know exactly where your embroidery will start. That means perfect placement every time.

Embroider at 1,000 SPM

Embrace larger, multicolored designs and watch them stitch in no time! The Alliance reliably works up to 1,000 stitches per minute.

Large Embroidery Field

In addition to its ability to negotiate tight spaces, the Alliance can expand its reach to an 8” x 8” hoop, giving the dedicated home embroiderer or business startup room to create.

Optional Cap Hoop and Cap Set

Embroider caps with speed and ease with this cap frame for your multi-needle embroidery machines. This snap-on frame allows you to effortlessly embroider along the curve of any cap. With additional cap frames, you can save time by having several caps hooped and ready to snap-in.

Automatic Needle Threader

Get the stitching started with worry-free threading. The automatic needle threader puts your thread through the needle so you are ready to begin stitching.

Multi-line Text & Justification

Now you can create multiple lines of text quickly and easily, without the need for constant rehooping. Plus, you can center or justify your text alignment to get precisely the look you desire.

25 Built-in Fonts

25 built-in, editable fonts to help you make every project unique, including a Large Floral Alphabet, Greek Letters, Large Appliqué Alphabet, and a Baby Lock exclusive font.

2 USB Drives (1 Type A, 1 Type B)

Use USB connectivity to quickly import designs to your machine from a computer, flash drive or CD-ROM drive. The Alliance USB drives support multiple design software formats.

Convenient Bobbin System

This front-loading bobbin system with a vertical hook makes bobbin changes a cinch. You never have to remove your embroidery hoop.

Quick-Set, Built-in Bobbin Winder

The Alliance bobbin system includes an automatic bobbin winder with an independent motor. The winder seat holds the thread in place and stops automatically when the bobbin is full.


Embroidery Capabilities Built-in embroidery design library: 141 Embroidery designs which include 90 Baby Lock exclusive designs 140 Frame Patterns 13 Font styles in upper and lower case including: Extra large block alphabet and characters (32 total Exclusive script alphabet and characters (72 total) Up to 5″ x 7″ (130mm x 180mm) embroidery field Reads embroidery designs with a stitch capacity of up to 200,000 stitches per design Memory for saving embroidery patterns up to 1MB Customize embroidery pattern and thumbnail background colors Embroidery design editing: Enlargement (up to 20%) Reduction (up to 10%) Mirror imaging 1°, 10°, and 90° pattern rotation LCD color touch screen shows Estimated embroidery time display and stitch count Needle position placement (1, 10, or 100 stitch increments) Measurements displayed in inches or millimeters Thread color indicator On-screen hoop size indicator 8-Point trial check points Thumbnail images viewed at 150% the normal size Embroidery speed up to 650 spm 300 Color names Advanced Sewing Features 250 Built-in stitches including: 91 Utility (with 10 styles of one-step buttonholes) 8 Directional Feeding stitches 50 Decorative 17 Satin 12 Decorative Satin 14 Cross stitch 58 Combinable utility stitches 5 Alphabet Styles Side Feeding Stitch length 0.0mm – 5.0mm on sewing stitches Maximum Utility stitch width: 7mm Sewing speed up to 850 spm Utility stitch editing capabilities: Store personal stitch settings for each utility stitch on machine Decorative stitch editing capabilities: Edit and combine Character/ Decorative stitches Up to 15 stitch patterns (total of about 128KB) can be saved in the machine’s memory Lock key for Utility and Decorative stitches Variable needle positions Back to the Beginning key returns to the beginning of a decorative stitch pattern Twin needle settings key Technology Features USB (Type A) LCD color touch screen (3.2″ x 1.8″) Advanced needle threader Automatic thread cutter Quick-Set, top-loading bobbin Quick-Set, bobbin winder Upper and lower thread sensors to alert when threads are broken 2 LED lights illuminate sewing surface Convenient Sewing Features Convenient One-Touch Buttons Start/Stop Reverse sewing Needle up/down Thread cutter Reinforcement Key Needle plate with scale in inches and centimeters Hands-free Presser Foot Lift Electronic foot control with separate power cord Free arm with drop feed lever Accessory storage compartment Additional Information Optional Extension Table (BLMCC-ET) Optional Embroidery Hoops Small 1″ x 2-1/2″ (20mm x 60mm) (EF82) Medium 4″ x 4″ (100mm x 100mm) (EF83) Straight Stitch Needle Plate and Foot Set (BLMAC-SS) Gold Standard Comprehensive Care Program (BLMCC) Instructional and Help Resources Built-in Operational Guide 18 Languages


  • Touch pen (stylus)
  • Accessory Case
  • Prewound bobbins
  • Metal bobbins
  • USB cable
  • Seam ripper
  • Scissors
  • Tweezers
  • Screwdrivers
  • Spool
  • Oiler
  • Tweezers
  • Spool caps
  • Cleaning brush
  • Embroidery frame holder “a”
  • Embroidery frame holder “e”
  • Embroidery hoops:
  • 8” x 8” hoop (200mm x 200mm) #ALF200
  • 4” x 4” hoop (100mm x 100mm) #EPF100
  • 1-5/8” x 2-3/4” hoop (41mm x 70mm) #ALF70
  • 2” x 2” hoop (50mm x 50mm) #ALF50
  • 1-1/2” x 1-3/4” hoop (38mm x 44mm) #ALF44
  • 1-15/16” x 2-15/16” hoop (33mm x 75mm) #ALF74
